Description
|
1. Membrane Type |
|
Cross Linked Fully Aromatic Polyamide Composite |
|
2. Test Conditions |
Feed Water Pressure Feed Water Temperature Feed Water Concentration Recovery Rate Feed Water pH |
225 psi (1.55MPa) 77°F (25°C) 2,000 mg/l NaCl 15% 7 |
|
3. Minimum Salt Rejection |
|
99.0% |
|
4. Minimum Product Flow Rate |
|
2,000gpd (7.6m³/d) (TM710) 7,500gpd (28.4m³/d) (TM720-370) 8,200gpd (31.0m³/d) (TM720-400) 9,000gpd (34.1m³/d) (TM720-440) |
Models
Specifications:
| Type |
Diameter Inch |
Membrane Area ft2(m2) |
Salt Rejection % |
Product Flow Rate gpd(m3 / d) |
Feed Spacer Thickness mil |
|
TM710 |
4” |
87(8) |
99.7 |
2,400(9.1) |
31 |
Features
Operating Limits
- Maximum Operating Pressure:600psi (4.1 MPa)
- Maximum Feed Water Temperature:113°F (45°C)
- Maximum Feed Water SDI15:5
- Feed Water Chlorine Concentration:Not Detectable
- Feed Water pH Range, Continuous Operation:2-11
- Feed Water pH Range, Chemical Cleaning:1-12
- Maximum Pressure Drop per Element:20psi (0.14 MPa)
- Maximum Pressure Drop per Vessel:60psi (0.4 MPa)
Applications
- Municipal industrial
- Process water
- Commercial applications
